Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels

Jiangyin Hongmao Decoration Material Co.,Ltd is just as the word : NOT FOR THE BIGGEST , BUT FOR THE BEST.

—— Mr James

I'm Online Chat Now

Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels

China Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels supplier
Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels supplier Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels supplier Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels supplier Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels supplier

Large Image :  Dust - Proof PVDF Paint Alum Composite Panel , Rustproof Architectural Metal Panels

Product Details:

Brand Name: OEM
Certification: ISO9001:2008 ISO14001:2015
Model Number: 4* 1570 * 3050mm (0.50/0.50)

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden packages or bare loading, according to customer's requirement
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union
Supply Ability: 250,000 + square meters + per month
Contact Now
Detailed Product Description
ALUMINUM ALLOY: AA3105, AA1100, AA3003, , AA5005 COLOR: Any Colors Are Available
SIZE: 4* 1570 * 3050mm (0.50/0.50) MOQ: 500 Sqm For A Single Color And A Single Width
Paint: FEVE Paint, PVDF Paint PACKAGES: Strong Wooden Packages
High Light:

aluminum composite building panels

,

aluminium covered composite panel

3 coats PVDF paint ACP Aluminium composite panel 4* 1570 * 3050mm (0.50/0.50) mm with paint thickness 35um

Dimensions:


4* 1570 * 3050mm (0.50/0.50) mm with paint thickness 35um
Non-standard width are available
Advantages:Lightweight and Rigidity compared with other products
Excellent Insulation of Thermal Conductivity
Anti-toxicity and Safety
Workability during installation

Excellent Coating

Color Uniformity and Durability during the warranty years
High Peeling Strength upto GB standard



Characteristics:
1. Standard:
Total thickness: 4mm
Alu. Thickness: 0.5mm
Width: 1220, 1250,1500,1550,2000mm Maximum 2000mm (Special width is also available)
Length: standard length 2440, 3000, 3660 ,4000 mm or any length you need

Option:
PVDF paint for your choice
Total thickness: 2mm - 8mm
Alu. Thickness: 0.3mm,0.4mm, 0.45mm, 0.5mm ,0.60mm ,0.70mm



PVDF / FEVE Paint Comparison
ITEM PVDF FEVE
Paint Thickness ≥ 25um ≥ 25um
Hardness of Pencil >F >2H
Coating temperature 232-249°C (15-10min ) 200-220°C (15-12min )
Solvent Resistance Clean 100times without change Clean 100times without change
Adhesion test 100% adhering 100% adhering
Salt Haze Resistance test 5% According to AAMA2605 standard According to AAMA2605 standard
Weather Resistance According to AAMA2605 standard According to AAMA2605 standard
Gloss Maintain According to AAMA2605 standard According to AAMA2605 standard
60°Mirror Gloss 15% -35% 15% -60%
Paint composition 70% PVDF Kynar 500 or Hylar 5000 100% Fluoropolymer (FEVE)
Cleaning Resistance ≥10000 times without change ≥10000 times without change
Acid Resistance Immerse Surface with 5% HCL(v/v) for 24h without change Immerse Surface with 5% NaOH(m/m) for 24h without change
Wear Resistance Good Good
Abrasion resistance over 40 over 50
Water sealing performance 38°Cx24 hours soaking 100% no bubble 100% no bubble
Color difference Installation technique affect more to the color difference Installation technique affect less to the color difference



Other specifications available, according to customers' requirements
3) Various colors available, according to customers' requirements
4) Easy installation, apparently shortened installation time
5) Efficiently lightened burden for walls
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) High impact resistance and good plasticity
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels


(Notes: Optional items & customers colors are subject to the respective minimum quantity. )

Package:
Strong wooden case
