Glossy Black / White Aluminum Clad Insulation Panels With Wind - Pressure Resistance

Large Image : Glossy Black / White Aluminum Clad Insulation Panels With Wind - Pressure Resistance

Product Details:

Brand Name:	OEM
Certification:	ISO9001:2008 ISO14001:2015
Model Number:	4* 1575 * 5000 (0.40/0.40) mm

Payment & Shipping Terms:

Minimum Order Quantity:	negotiation
Price:	negotiation
Packaging Details:	wooden packages or bare loading, according to customer's requirement
Delivery Time:	15 days
Payment Terms:	D/A, L/C, D/P, T/T, Western Union
Supply Ability:	250,000 + square meters + per month

Contact Now

Detailed Product Description

ALUMINUM ALLOY:	AA1100, AA3003, AA3105, AA5005	COLOR:	Any Colors Are Available
PACKAGES:	Strong Wooden Packages	SIZE:	4* 1575 * 5000 (0.40/0.40) Mm
Coating:	POLYESTER PAINTS	MOQ:	1000 Sqm For A Single Specification
High Light:	aluminum composite building panels , aluminium covered composite panel

Glossy Black / Glossy Matt ACP Aluminium composite panel 4* 1575 * 5000mm (0.40/0.40) mm with Polyester paint

Dimensions:
4* 1575 * 5000mm (0.40/0.40) mm

Workability during installation
Non-standard width are available for your choice
Advantages:

Lightweight and Rigidity compared with other products
Excellent Insulation of Thermal Conductivity
Anti-toxicity and Safety

Excellent Coating
Color Uniformity and Durability during the warranty years
High Peeling Strength upto GB standard

Characteristics:
1. Standard:
Width: from 915mm to 2,000mm with Maximum 2000mm (Special width is also available for your choice)
Length: standard width 2440mm, 3050mm, 3660mm ,4880mm ,5000mm ,5700 mm or any length upon your requirement

Items (POLYESTER ACP)		Standard Index	Result	Conclusion
Appearance		Clean Surface without swell, scrath and aberration	Pass	Qualified
Deviation of Dimension		Deviation of Diagonal: ≤5mm	1mm	Qualified
Thickness of Coating		≥18um	19um	Qualified
Hardness of Pencil		≥HB	2H	Qualified
Toughness of Coating		≤2T	2T	Qualified
Impact Strength		30 Kg.cm Without paint off and crack	Pass	Qualified
Boiling Water Resistance		Boiling for 2h without change	Unchanged	Qualified
Acid Resistance		Immerse Surface with 2% HCI(v/v) for 24h without change	Unchanged	Qualified
Alkali Resistance		Immerse Surface with 2% NaOH(m/m) for 24h without change	Unchanged	Qualified
Solvent Resistance		Clean 200 times without change	Bottom unrevealed	Qualified
Cleaning Resistance		≥10000 times without change	Unchanged	Qualified
Bend Strength		≥100Mpa	121Mpa	Qualified
Flexuous Modulus of Elasticity		≥2.0x10 4 Mpa	3.12x10 4 Mpa	Qualified
Cutting Strength		≥28.0 Mpa	32.0 Mpa	Qualified
180°Peel strength		≥7.0 N/mm	11.2N/mm	Qualified
Salt Haze Resistance(3000h)		Not less than Grade 2	Grade 1	Qualified
Artificial Weathering(4000h)	Artificial Resistance Aberration	≤4.0	1.24	Qualified
Artificial Weathering(4000h)	Aging Resistance out of Light	Not less than Grade 2	Grade 1	Qualified

Polyester / Primer paint

Other specifications available, according to customers' requirements
3) Various colors available, according to customers' requirements
4) High impact resistance and good plasticity
5) Efficiently lightened burden for walls
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened installation time
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels

(Notes: Optional items & customers colors are subject to the respective minimum quantity. )

Package:
Strong wooden case
