Product Details:
Payment & Shipping Terms:
|
ALUMINUM ALLOY: | Alloy 1100, Alloy 3003, Alloy 5005 | PACKAGES: | Strong Wooden Packages |
---|---|---|---|
SIZE: | 6* 1550 * 5200mm (0.50/0.50mm) | MOQ: | 700 Sqm For A Single Color And A Single Width |
Paint: | FEVE Paint, PVDF Paint | COLOR: | Custom Colors Are Available For You |
High Light: | aluminum composite building panels,aluminium covered composite panel |
Spectra Green color ACP Aluminium composite panel 6* 1550 * 5200mm (0.50/0.50mm) with PVDF paint
Dimensions:
6* 1550 * 5200mm (0.50/0.50mm)
Non-standard width are available
Advantages:
High Peeling Strength of aluminium and LDPE core
Lightweight and high Rigidity
Excellent Insulation of Thermal Conductivity compared with other products
Anti-toxicity and Safety
Workability during installation
Excellent coats
Color Uniformity and Durability during the warranty years
Characteristics:
1. Standard:
Width: from 1,100mm to 2,000mm special width is also available for you
Length: standard length 2400mm, 3050mm, 3660mm ,4880mm ,5000mm , 5500 mm or other length upon your requirement
Items (PVDF ACP) | Standard Index | Result | Conclusion | |
Appearance | Clean Surface without swell, scrath and aberration | Pass | Qualified | |
Deviation of Dimension | Deviation of Diagonal: ≤5mm | 1mm | Qualified | |
Thickness of Coating | ≥25um | 27u(av.30) | Qualified | |
Hardness of Pencil | ≥HB | H | Qualified | |
Toughness of Coating | ≤2T | 2T | Qualified | |
Impact Strength | 50 Kg.cm Without paint off and crack | Pass | Qualified | |
Boiling Water Resistance | Boiling for 2h without change | Unchanged | Qualified | |
Acid Resistance | Immerse Surface with 5% HCI(v/v) for 24h without change | Unchanged | Qualified | |
Alkali Resistance | Immerse Surface with 5% NaOH(m/m) for 24h without change | Unchanged | Qualified | |
Solvent Resistance | Clean 100times without change | Bottom unrevealed | Qualified | |
Cleaning Resistance | ≥10000 times without change | Unchanged | Qualified | |
Bend Strength | ≥100Mpa | 121Mpa | Qualified | |
Flexuous Modulus of Elasticity | ≥2.0x10 4 Mpa | 3.12x10 4 Mpa | Qualified | |
Cutting Strength | ≥28.0 Mpa | 32.0 Mpa | Qualified | |
180°Peel strength | ≥7.0 N/mm | 11.2N/mm | Qualified | |
Salt Haze Resistance(3000h) | Not less than Grade 2 | Grade 1 | Qualified | |
Artificial Weathering(4000h) | Artificial Resistance Aberration | ≤4.0 | 1.24 | Qualified |
Aging Resistance out of Light | Not less than Grade 2 | Grade 1 | Qualified |
Other specifications available, according to customers' requirements
3) Efficiently lightened burden for wall cladding
4) High impact resistance and good plasticity
5) Various colors available, according to customers' requirements
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened the installation period
10) Quality warranty:
A) 20-year warranty years for PVDF aluminum composite panel
(Notes: Optional items & customers colors are subject to the respective minimum quantity. )
Package:
Strong wooden packages
