Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet

Jiangyin Hongmao Decoration Material Co.,Ltd is just as the word : NOT FOR THE BIGGEST , BUT FOR THE BEST.

—— Mr James

I'm Online Chat Now

Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet

China Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet  supplier
Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet  supplier Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet  supplier

Large Image :  Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet

Product Details:

Brand Name: OEM
Certification: ISO9001:2008 ISO14001:2015
Model Number: 4*1220* 2440mm (0.30/0.30mm)

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden packages or bare loading, according to customer's requirement
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union
Supply Ability: 250,000 + square meters + per month
Contact Now
Detailed Product Description
SPECIFICATION: 4*1220* 2440mm (0.30/0.30mm) COLORS: Custom Colors Are Available For You
MOQ: 1000 Sqm For A Single Specification Paint: FEVE Paint, PVDF Paint
PACKING: Strong Wooden Cases With Fumigation ALUMINUM ALLOY: AA1100, AA3003, AA3105, AA5005
High Light:

aluminum coated plastic sheet

,

aluminium composite panel sheet

PVDF paint Aluminium Composite sheets 4*1220* 2440mm (0.30/0.30mm) with pearl green

Dimensions:
4*1220* 2440mm (0.30/0.30mm)



Our Features and Scope in details
Features Super peeling strength/ Good temperature adaptability/ Excellent performance of fireproof/ Weather proof/ Quickly installed/ Excellent self-cleaning character
Scope Curtain wall of buildings/ Roof & house eave/ Wall board, movable house/ Display trestle/ Vehicle wagon,yacht interior & exterior/Old building exterior wall face-lifting/ Balcony, comportment/ Door decoration/ Signboard, advertisement board/ Machine, apparatus casing.


Advantages:
Color Uniformity and Durability within the warranty years

Workability

Excellent Coating and smooth colors
High Peeling Strength upto GB standard
Lightweight and Rigidity
Excellent Insulation of Thermal Conductivity
Anti-toxicity and Safety



PVDF / FEVE Paint Comparison
ITEM PVDF coat FEVE coat
Paint Thickness ≥ 25um ≥ 25um
Hardness of Pencil >F >2H
Coating temperature 232-249°C (15-10min ) 200-220°C (15-12min )
Solvent Resistance Clean 100times without change Clean 100times without change
Adhesion test 100% adhering 100% adhering
Salt Haze Resistance test 5% According to AAMA2605 standard According to AAMA2605 standard
Weather Resistance According to AAMA2605 standard According to AAMA2605 standard
Gloss Maintain According to AAMA2605 standard According to AAMA2605 standard
60°Mirror Gloss 15-35 15-60
Paint composition 70% PVDF Kynar 500 or Hylar 5000 100% Fluoropolymer (FEVE)
Cleaning Resistance ≥10000 times without change ≥10000 times without change
Acid Resistance Immerse Surface with 5% HCL(v/v) for 24h without change Immerse Surface with 5% NaOH(m/m) for 24h without change
Wear Resistance Good Good
Abrasion resistance over 40 over 50
Water sealing performance 38°Cx24 hours soaking 100% no bubble 100% no bubble
Color difference Installation technique affect more to the color difference Installation technique affect less to the color difference


Specifications:
1. Standard:
Total thickness: 4mm
Alu. Thickness: 0.5mm
Width: 1220, 1250,1500,1550,2000mm (Special width is also available) Maximum 2000mm
Length: standard length 2440mm,3050mm,3660mm, 5000mm or any length you need

Option:
PVDF paint
Total thickness: 2mm - 8mm
Alu. Thickness: 0.3mm, 0.35mm, 0.4mm, 0.45mm, 0.5mm ,0.60mm

Other specifications available, according to customers' requirements
3) Various colors available, according to customers' requirements
4) High impact resistance and good plasticity
5) Efficiently lightened burden for walls
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened installation time
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels


(Notes: Optional items & customers colors are subject to the respective minimum quantity. )

Package:
Strong wooden case



Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet Lightweight Green Aluminium Composite Sheet , Decorative Aluminum Sheet
