SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish

Jiangyin Hongmao Decoration Material Co.,Ltd is just as the word : NOT FOR THE BIGGEST , BUT FOR THE BEST.

—— Mr James

I'm Online Chat Now

SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish

China SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish supplier
SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish supplier SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish supplier SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish supplier

Large Image :  SUS304 Stainless Steel Composite Panel 3mm - 6mm Thickness With Dull Finish

Product Details:

Brand Name: OEM
Certification: ISO9001:2008
Model Number: 1220*4200*5mm (0.30/0.30mm)

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Strong wooden packages according to customer requirements
Delivery Time: 20 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 31,000 + square meters + per month
Contact Now
Detailed Product Description
SPECIFICATION: 1220*4200*5mm (0.30/0.30mm) MOQ: 300 Square Meters For A Single Dimension
TYPES: SUS304, SUS316 PACKAGE: Wooden Packages With Fumigation For Your Choice
High Light:

stainless steel wall panels

,

stainless steel wall cladding

SUS304 Stainless steel composite panel 1220*4200*5mm (0.30/0.30mm) with Dull finish

Dimension: 1220*4200*5mm (0.30/0.30mm)

  • Usage: External Wall, Curtain Wall, Interior, Escalator and Elevator Cladding, Curtain Walls
  • Structure: Sandwich Composite Panel
  • Grade of Stainless Steel: 304, 316, 220m
  • Skin Thickness: 0.3mm, 0.4mm, 0.5mm
  • Trademark: ALUONTOP OR CUSTOM BRAND
  • Specification: Exterior Facade Panel
  • Thickness: 3mm, 4mm, 5mm, 6mm
  • Core: Fr, LDPE
  • Transport Package: Strong Wooden Pallets with fumigation
  • Model NO.: SSCP
  • Panel Thickness: 3mm,4mm,5mm
  • Function: Fireproofing, Anti-static
  • Certification: CE, ASTM, ISO
  • Raw Material: Stainless Steel Sheet / Plastic Core
  • Surface Finishing: Mirror Surface

Finishes: Dull finish, Polished finish, Brush finish, Embossed finish



Characteristics for Stainless Steel Composite Panel :
Test Item Unit Performance indicators
3(4) x0.30/0.30mm 3(4) x0.20/0.20mm 3(4) x0.10/0.10mm
Roller Peel-off Strength N·mm/mm ≥130 ≥130 ≥130
Unit Weight km/m² 7.0±0.5 (8.0±0.5) 5.6±05 (6.5±0.5) 4.1±0.5 ( 5.0±0.5)
Flexural Strength MPa ≥130.0 ≥125.0 ≥70.0
Flexural Modulus 104Mpa ≥3.5 ≥3.2 ≥2.5
Penetrating Resistance kN ≥20 ≥15 ≥8.0
Shear Strength MPa ≥68 ≥58 ≥30
Thermal Expansion /℃ ≤1.8×10-5 ≤1.8x10-5 ≤1.8x10-5
Thermal Deformation Temperature ≥105 ≥105 ≥105
Boiling-water Resistance   No Effect No Effect No Effect
Weather Resistance   No Effect No Effect No Effect
Same Rigidity as Stainless Steel mm 2.4 2.4 2.1
Fire Resistance GB8642 CLASS B(ONLY FOR FR PANELS)
Total Thickness: 3mm-6mm standard, up to 15mm optional
Top Skin: Stainless Steel Skin (Hairline, Mirror, Embossed, Dull etc) in 0.3mm or 0.4mm
Core: Mineral FR material
Bottom: Stainless Steel Skin mill finish (2B) for standard, other finish optional

Size and Specifications 4mm FR core
Finish Face Skin Bottom Skin Core Standard Width Optional Width # of stainless
Hairline 0.4mm 0.4mm FR 1200mm 1000mm, 1500mm #304 #316 #220M
Mirror 0.3mm 0.3mm FR 1200mm N/A #304 #316
Embossed 0.4mm 0.4mm FR 1200mm N/A #304 #316
Dull Finish 0.3mm 0.3mm FR 1200mm N/A #304 #316 #220M
