Product Details:
Payment & Shipping Terms:
|
ALUMINUM ALLOY: | AA3105, AA1100, AA3003, , AA5005 | COLOR: | Any Colors Are Available For You To Choose |
---|---|---|---|
SIZE: | 3* 1500 * 5100mm (0.30/0.30mm) | MOQ: | 600 Sqm For A Single Color And A Single Width |
Paint: | FEVE Paint, POLYESTER Paint | PACKAGES: | Strong Wooden Packages For Your Choice |
High Light: | aluminium composite plate,pvdf coating aluminium composite panel |
Pearl pink color PVDF Aluminum Composite Panel 3* 1500 * 5100mm (0.30/0.30mm) with 3 coats
Dimensions:
3* 1500 * 5100mm (0.30/0.30mm)
Non-standard width are available
Advantages:
1) Free sample will be provided within 5 days by DHL
2) Any inquiry will be replied within 5 hours
3) OEM and ODM are available
4) Strict inspection process for all batches
5) Supply certification of SGS,Fireproof Certification, Soundproof Certification.
Excellent Coating
Color Uniformity and Durability during the 15 years
High Peeling Strength upto GB standard
Lightweight and good Rigidity
Excellent Insulation of Thermal Conductivity
Anti-toxicity and Safety
Workability
PVDF / FEVE Paint Comparison | ||
ITEM | PVDF | FEVE |
Paint Thickness | ≥ 25um | ≥ 25um |
Hardness of Pencil | >F | >2H |
Coating temperature | 232-249°C (15-10min ) | 200-220°C (15-12min ) |
Solvent Resistance | Clean 100times without change | Clean 100times without change |
Adhesion test | 100% adhering | 100% adhering |
Salt Haze Resistance test 5% | According to AAMA2605 standard | According to AAMA2605 standard |
Weather Resistance | According to AAMA2605 standard | According to AAMA2605 standard |
Gloss Maintain | According to AAMA2605 standard | According to AAMA2605 standard |
60°Mirror Gloss | 15-35 | 15-60 |
Paint composition | 70% PVDF Kynar 500 or Hylar 5000 | 100% Fluoropolymer (FEVE) |
Cleaning Resistance | ≥10000 times without change | ≥10000 times without change |
Acid Resistance | Immerse Surface with 5% HCL(v/v) for 24h without change | Immerse Surface with 5% NaOH(m/m) for 24h without change |
Wear Resistance | Good | Good |
Abrasion resistance | over 40 | over 50 |
Water sealing performance 38°Cx24 hours soaking | 100% no bubble | 100% no bubble |
Color difference | Installation technique affect more to the color difference | Installation technique affect less to the color difference |
Specifications:
1. Standard:
Total thickness: 4mm
Alu. Thickness: 0.5mm
Width: 1220, 1250,1500,1550,2000mm (Special width is also available) Maximum 2000mm
Length: standard length 2440mm,3050mm,3660mm, 5000mm or any length you need
Option:
PVDF paint
Total thickness: 2mm - 8mm
Alu. Thickness: 0.3mm, 0.35mm, 0.4mm, 0.45mm, 0.5mm ,0.60mm
Other specifications available, according to customers' requirements
3) Strengthened impact resistance for constructions
4) High impact resistance and good plasticity
5) Efficiently lightened burden for walls
6) Various colors available, according to customers' requirements
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened installation time
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels
(Notes: Optional items & customers colors are subject to the respective minimum quantity. )
Package:
Strong wooden package
