Fire Resistant PVDF Aluminum Decorative Panels For Cabinet / Ceiling / Roof

Jiangyin Hongmao Decoration Material Co.,Ltd is just as the word : NOT FOR THE BIGGEST , BUT FOR THE BEST.

—— Mr James

I'm Online Chat Now

Fire Resistant PVDF Aluminum Decorative Panels For Cabinet / Ceiling / Roof

China Fire Resistant PVDF Aluminum Decorative Panels For Cabinet / Ceiling / Roof supplier

Large Image :  Fire Resistant PVDF Aluminum Decorative Panels For Cabinet / Ceiling / Roof

Product Details:

Brand Name: OEM
Certification: ISO9001:2008 ISO14001:2015
Model Number: 4* 1250 * 4000mm (0.70/0.50mm)

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden packages or bare loading, according to customer's requirement
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union
Supply Ability: 250,000 + square meters + per month
Contact Now
Detailed Product Description
ALUMINUM ALLOY: AA3003, AA3105, AA5005 COLOR: Custom Colors Are Available For You
PACKAGES: Strong Wooden Packages SIZE: 4* 1250 * 4000mm (0.70/0.50mm)
MOQ: 1200 Sqm For A Single Color And A Single Width Paint: FEVE , PVDF
Thickness: 4mm-6mm CORE: Fire Resistant Core
High Light:

aluminium composite plate

,

pvdf coating aluminium composite panel

Fire resistant PVDF Aluminum Composite Panel 4* 1250 * 4000mm (0.70/0.50mm) for wall cladding

Dimensions:
4* 1250 * 4000mm (0.70/0.50mm)
Non-standard width and length are available


Advantages:

Excellent Fire resistant with A2 grade

Lightweight and Rigidity
Color Uniformity and Durability during the warranty years
High Peeling Strength upto GB standard
Excellent Insulation of Thermal Conductivity
Anti-toxicity and Safety
Workability

Excellent Coating



Items (FIRE RETARDANT PVDF Aluminum Composite Panel) Standard Index Result Conclusion
Appearance Clean Surface without swell, scrath and aberration Pass Qualified
Deviation of Dimension Deviation of Diagonal: ≤5mm 1mm Qualified
Thickness of Coating ≥25um 27u(av.30) Qualified
Hardness of Pencil ≥HB H Qualified
Toughness of Coating ≤2T 2T Qualified
Impact Strength 50 Kg.cm Without paint off and crack Pass Qualified
Boiling Water Resistance Boiling for 2h without change Unchanged Qualified
Acid Resistance Immerse Surface with 5% HCI(v/v) for 24h without change Unchanged Qualified
Alkali Resistance Immerse Surface with 5% NaOH(m/m) for 24h without change Unchanged Qualified
Solvent Resistance Clean 100times without change Bottom unrevealed Qualified
Cleaning Resistance ≥10000 times without change Unchanged Qualified
Bend Strength ≥100Mpa 121Mpa Qualified
Flexuous Modulus of Elasticity ≥2.0x10 4 Mpa 3.12x10 4 Mpa Qualified
Cutting Strength ≥28.0 Mpa 32.0 Mpa Qualified
180°Peel strength ≥7.0 N/mm 11.2N/mm Qualified
Salt Haze Resistance(3000h) Not less than Grade 2 Grade 1 Qualified
Artificial Weathering(4000h) Artificial Resistance Aberration ≤4.0 1.24 Qualified
Aging Resistance out of Light Not less than Grade 2 Grade 1 Qualified


Specifications:
1. Standard:
Total thickness: 4mm
Alu. Thickness: 0.70/0.50mm
Width: 1220, 1250,1500mm
Length: standard length 2440mm,3050mm,3660mm, 5000mm or any length you need


Other specifications available, according to customers' requirements
3) Various colors available, according to customers' requirements
4) High impact resistance and good plasticity
5) Efficiently lightened burden for walls
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened installation time
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels


(Notes: Optional items & customers colors are subject to the respective minimum quantity. )

Package:
Strong wooden package
