Various Colors Aluminium Wall Cladding Panels With High Impact Resistance

Jiangyin Hongmao Decoration Material Co.,Ltd is just as the word : NOT FOR THE BIGGEST , BUT FOR THE BEST.

—— Mr James

I'm Online Chat Now

Various Colors Aluminium Wall Cladding Panels With High Impact Resistance

China Various Colors Aluminium Wall Cladding Panels With High Impact Resistance supplier
Various Colors Aluminium Wall Cladding Panels With High Impact Resistance supplier Various Colors Aluminium Wall Cladding Panels With High Impact Resistance supplier

Large Image :  Various Colors Aluminium Wall Cladding Panels With High Impact Resistance

Product Details:

Brand Name: OEM
Certification: ISO9001:2008 ISO14001:2015
Model Number: 4* 2000 * 5500mm (0.40/0.40mm)

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden packages or bare loading, according to customer's requirement
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union
Supply Ability: 250,000 + square meters + per month
Contact Now
Detailed Product Description
ALUMINUM ALLOY: AA1100, AA3003, COLOR: Standard Colors And Custom Colors Are Available
SIZE: 4* 2000 * 5500mm (0.40/0.40mm) MOQ: 500 Sqm For A Single Color And A Single Width
Paint: FEVE , PVDF PACKING: Strong Wooden Cases
High Light:

aluminium covered composite panel

,

aluminum composite metal panels

Champagne Silver color ACP Aluminium composite panel 4* 2000 * 5500mm (0.40/0.40mm) with PVDF paint



Dimensions:
4* 2000 * 5500mm (0.40/0.40mm)
Other specifications available, according to customers' requirements

1 Protective film with ALUONTOP or OEM brand or as your request
2 Front side: aluminum coils coated with PVDF paint
3 Macromolecular lamination film
4 Core: Non-toxic polyethylene.
5 Macromolecular lamination film.
6 Rear side: Aluminum coated with primer or as requested.



Test Item Technical Specifications Dependencies

Appearance

Surface Coating to be smooth, uniform,no abnormal

GB9761

Adhesion ≧Grade 0 GB/T 9268-88
Gloss 60 ° angle,Total specular reflection luster GB/T 9754-88
Pencil Hardness ≧HB;No Scratching GB/T 6739-1996
Impact Resistance(kg×cm) ≧50 Without Peeling,and Cracking;∮12.7mm GB/T 1732-93
Flexibility ≦3T GB 6742-86

Cupping Test

5mm; Without chapping , stripping GB9753-88
Solvent Resistance(MEK) >100 times, No Exposure of Substrates ASTM D2248-73
Boiling water Resistance 98±2℃×2HRS ASTM D3359-B
Oil Marker Pen Test Stroke with marker pen and, wipe off / no traces ------

QUV Resistance Test

(1000 Hr)

Color Retention: ΔE≦3 GB/T 11186
Gloss Retention; ≧Grade 2 GB/T 9754
Baking Condition 232℃~241℃×100s ------



Characteristics:
1. Standard:
Total thickness: 4mm
Alu. Thickness: 0.40/0.40mm
Width: from 1,000mm to 2,000mm Maximum 2000mm (Special width is also available)
Length: standard length 2000mm, 3050mm, 3660mm ,4880mm ,5000mm ,5700 mm or any length upon your requirement

2) OEM and OEM colors for your choice.
3) Various colors available, according to customers' requirements
4) High impact resistance and good plasticity
5) Efficiently lightened burden for walls
6) Strengthened impact resistance for constructions
7) Great weather adaptabilities, high intensity, and easy maintenance
8) Perfect sound insulation, thermal resistance and fire retardant capability
9) Easy installation, apparently shortened installation time
10) Quality warranty:
A) 20-year guarantee for PVDF aluminum composite panels


(Notes: Optional items & customers colors are subject to the respective minimum quantity. )

Package:
Strong wooden case

Various Colors Aluminium Wall Cladding Panels With High Impact ResistanceVarious Colors Aluminium Wall Cladding Panels With High Impact Resistance
